CNC precision surface grinding machine

Offer details

Manufacturer
BLOHM
Type
PLANOMAT 616 - CNC
Year
2000
Delivery time
immediately
Freight basis
ex stock
Type of control
CNC
Control
SIEMENS SINUMERIK 810D
Storage location
Halberstadt
Country of origin
Germany

Workpiece spindle speed range
1000 - 3400 RPM
Grinding Length
1600 mm
Grinding Width
600 mm
Table Surface Area
1500 x 600 mm

Additional information
- Grinding spindle with facing unit
- Grinding spindle drive by controlled three-phase motor with frequency converter (15 kW from 1000-3400 rpm)
- Enable peripheral speed up to max. 60 m/s
- Program for reading in/out/editing NC (main and secondary) programs
- Profile grinding unit PEA-TL200 for dressing with diamond profiling rollers
- Grinding wheel holder
- Automatic balancing device
- Paper belt filter unit
- Cooling unit 3.8 KW
- Electro-Permanent magnetic clamping plate 1500 x 600 mm, with 18 mm continuous cross-pole spacing and substructure
- Extension of NC memory by 256 kB
- ECO grinding program for rough grinding using the pendulum infeed method
- Menu-guided surface grinding in 3 shifts
